Crypto Mining
This motherboard is specifically designed for mining, the revolutionary digital crypto-currency that may be used anywhere in the world. The abundant onboard PCIe slots guarantee fast Crypto mining, while the additional power connectors provide advanced system stability while mining.
M.2 For SSD
M.2 socket supports 2260/2280/22110 SATA3 mode M.2 SSD for up to 6Gb/s
Smart PCIe State Detection
This motherboard has included a smart way to show the status of every graphics card. While the system is booting, the Power-On, Self-Test (POST) screen will show the status of the graphics cards that were installed on the motherboard.
Intel LAN
Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users
Power On / Reset Button
Power On & Off system with onboard button is a must for open frame mining.
Digi Power
Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced.
Full Spike Protection
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.
CPU
- Supports 7th and 6th Generation Intel Core i5/i3/Pentium/Celeron Processors (Socket 1151) Supports CPU up to 91W- Digi Power design 6 Power Phase design Supports Intel Turbo Boost 2.0 Technology
Memory
- Dual Channel DDR4 Memory Technology 2 x DDR4 DIMM SlotsSupports DDR4 2400 / 2133 non-ECC, un-buffered memory Supports ECC UDIMM memory modules (operate in non-ECC mode) Max. capacity of system memory: 32GB Supports Intel Extreme Memory Profile (XMP) 2.0 15μ Gold Contact in DIMM Slots
BIOS
- 128Mb AMI UEFI Legal BIOS with multilingual GUI support, ACPI 6.0 Compliant wake up events, SMBIOS 2.7 Support, CPU, GTCPU, DRAM, PCH 1.0V, VCCIO Voltage Multi-adjustment
Graphics
- Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) 24Hz / (3840x2160) 30Hz, Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required), Supports HDCP 1.4 with HDMI 1.4 Port, Supports Full HD 1080p Blu-ray (BD) playback with HDMI 1.4 Port
Audio
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec), - Supports Surge Protection
LAN
- Gigabit LAN 10/100/1000 Mb/s, Giga PHY Intel I219V, Supports Wake-On-LAN, Supports Lightning/ESD Protection, Supports Energy Efficient Ethernet 802.3az, Supports PXE
Slots
- 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode), 12 x PCI Express 3.0 x1 Slots
Storage
- 4 x SATA3 6.0 Gb/s Connectors, 1 x M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module
Connector
- 1 x System Panel Header,1 x TPM Header, 1 x COM Port Header ,1 x Chassis Intrusion and Speaker Header, 1 x CPU Fan Connector (4-pin), 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control), 1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector, 2 x PCIe Power Connectors, 1 x SATA Power Connector, 1 x Front Panel Audio Connector, 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection), 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection), 1 x Power Button, 1 x Reset Button
Rear Panel I/O
- 1 x PS/2 Mouse Port, 1 x PS/2 Keyboard Port, ,1 x HDMI Port ,4 x USB 2.0 Ports (Supports ESD Protection), 2 x USB 3.2 Gen1 Ports (Supports ESD Protection), 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), HD Audio Jacks: Line in / Front Speaker / Microphone
Unique Feature
- ASRock Super Alloy: Premium 45A Power Choke, Sapphire Black PCB, High Density Glass Fabric PCB, ASRock Full Spike Protection ,ASRock Live Update & APP Shop
Hardware Monitor
- CPU/Chassis Fan Tachometer, CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature), CASE OPEN detectionW Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
Form Factorr
- ATX Form Factor: 12.0-in x 8.2-in, 30.5 cm x 20.8 cm, Solid Capacitor design
OS
- Microsoft Windows 10 64-bit (For 7th Gen Intel CPU), Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel CPU)
